Width: 290mm
Height: 1800mm
Pipe Centres: 290mm + Valves
Wall to Pipe Centres: 51mm
Total Projection: 93.50mm
Heat Output: 846 Watt - 2887 BTU/h @ Delta 50
Finish: Gloss / White (RAL Code: 9016)
Material: Steel
Design: Oval Tube Design, Double Row
Usage: Central Heating
Testing Pressure: 0.8 mpa
Working Pressure: 0.3 mpa
Gross Weight: 34 kg
Net Weight: 32.5 kg
Orientation: Vertical
Horizontal Tubes: n/a
Vertical Tubes: 10 (5x2)
Tube Layout: n/a
Number of Gaps: n/a
Mountings: Fixing brackets, plugs, screws and airvent
Guarantee: 10 Years
