Width: 406mm
Height: 1600mm
Pipe Centres: 406mm + Valves
Wall to Pipe Centres: 51mm
Total Projection: 93.50mm
Heat Output: 745 Watt - 2542 BTU/h @ Delta 50
Finish: Gloss / White (RAL Code: 9016)
Material: Steel
Design: Oval Tube Design, Single Row
Usage: Central Heating
Testing Pressure: 0.8 mpa
Working Pressure: 0.3 mpa
Gross Weight: 17.7 kg
Net Weight: 16.2 kg
Orientation: Vertical
Horizontal Tubes: n/a
Vertical Tubes: 7
Tube Layout: n/a
Number of Gaps: n/a
Mountings: Fixing brackets, plugs, screws and airvent
Guarantee: 10 Years
