Width: 600mm
Height: 800mm
Pipe Centres: 555mm
Wall to Pipe Centres: 75-90mm
Total Projection: 90-105mm
Heat Output: 319 Watt - 1090 BTU/h @ Delta 50
Pressure:Maximum working pressure 7 bar
Finish: Chrome Plated
Material: Steel
Design: Flat
Usage: Central heating / Electric only / Dual fuel (Please note additional parts will be required for each usage type)
Orientation: Vertical
Horizontal Tubes: 14 (Round 22mm Diameter)
Vertical Tubes: 2 (D Profile)
Tube Layout: 4 + 10
Number of Gaps: 1
Mountings: 4 x adjustable brackets, plugs, screws and airvent
Guarantee: 5 Years
