Width: 600mm
Height: 1800mm
Pipe Centres: 555mm
Wall to Pipe Centres: 70-85mm
Total Projection: 85-100mm
Heat Output: 752 Watt - 2565 BTU/h @ Delta 50
Water Intake:
Pressure:8 Bar (Safety Tested)
Finish: White Coated
Material: Steel
Design: Flat
Usage: Central heating / Electric only / Dual fuel (Please note additional parts will be required for each usage type)
Orientation: Vertical
Horizontal Tubes: 27 (Round 22mm Diameter)
Vertical Tubes: 2 (D Profile 40mm x 30mm)
Tube Layout: 9 + 6 + 5 + 4 + 3
Number of Gaps: 4
Mountings: 4 x adjustable brackets, plugs, screws and airvent
Guarantee: 5 Years
