Width: 600mm
Height: 1600mm
Pipe Centres: 550mm
Wall to Pipe Centres: 76.5 - 86.5mm
Total Projection: 91.5 - 101.5mm
Heat Output: 757 Watt - 2583 BTU/h @ Delta 50
Water Intake:7.36 litres
Pressure:8 Bar
Finish: Matte Black (RAL 9005)
Material: Steel
Design: Flat
Usage: Central heating / Electric only / Dual fuel
(Please note additional parts will be required for each usage type)
Orientation: Vertical
Horizontal Tubes: 26 (Round 22mm Diameter)
Vertical Tubes: 2 (D Profile 40mm x 30mm)
Tube Layout: 4+6+6+10
Number of Gaps: 3
Mountings: 4 x adjustable brackets, plugs, screws and airvent
Guarantee: 5 Years
