Width: 500mm
Height: 1750mm
Pipe Centres: 450mm
Wall to Pipe Centres: 75-95mm
Total Projection: 90-110mm + Curve
Heat Output: 595 Watt - 2029 BTU/h @ Delta 50
Water Intake: 7.88 litres
Pressure:8 Bar (Safety Tested)
Finish: Chrome Plated
Material: Steel
Design: Curved
Usage: Central heating / Electric only / Dual fuel (Please note additional parts will be required for each usage type)
Orientation: Vertical
Horizontal Tubes: 35 (Round 22mm Diameter)
Vertical Tubes: 2 (D Profile 40mm x 30mm)
Tube Layout: 14 + 8 + 5 + 5 + 3
Number of Gaps: 4
Mountings: 4 x adjustable brackets, plugs, screws and airvent
Guarantee: 5 Years
