Width: 400mm
Height: 800mm
Pipe Centres: 350mm
Wall to Pipe Centres: 76-86mm
Total Projection: 91-101mm
Heat Output: 163 Watt - 556 BTU/h @ Delta 50
Pressure:8 Bar (Safety Tested)
Finish: Chrome Plated
Material: Mild Steel
Design: Straight round-tube horizontal bars with D-shape vertical bars
Usage: Central heating / Electric only / Dual fuel (Please note additional parts will be required for each usage type)
Orientation: Vertical
Horizontal Tubes: 14 (Round 22mm Diameter)
Vertical Tubes: 2 (D Profile 40mm x 30mm)
Tube Layout: 10 + 4
Number of Large Gaps: 1
Mountings: 4 x adjustable brackets, plugs, screws and airvent
Guarantee: 5 Years
