Width: 400mm
Height: 1400mm
Pipe Centres: 350mm
Wall to Pipe Centres: 76 - 86 mm
Total Projection: 91-101 mm
Heat Output: 290 Watt - 990 BTU/h @ Delta 50
Pressure:8 Bar (Safety Tested)
Finish: Chrome Plated
Material: Steel
Design: Flat (Straight horizontal rungs)
Usage: Central heating / Electric only / Dual fuel (Please note additional parts will be required for each usage type)
Orientation: Vertical
Horizontal Tubes: 22 (Round 22mm Diameter)
Vertical Tubes: 2 (D Profile 40mm x 30mm)
Tube Layout: 6 + 6 + 6 + 4
Number of Gaps: 3
Mountings: 4 x adjustable brackets, plugs, screws and airvent
Guarantee: 5 Years
